Fluting
$533.00
Item #
Application
X
  • Imperial: 1A1 5"x.393"x.590" T=.393" Bore 1.25" Grit D280 Concentration SQ125 Hybrid Bond HP3 (Approx.)
  • Metric: 1A1 125x10x15 T=10 Bore 31.75 Grit D64 Concentration SQ125 Hybrid Bond HP3
  • Most Common Application: Fluting on CNC grinding machine, with high pressure coolant delivery lines. Excellent corner retention, best market option for manufacturing.
  • Recommended workpiece: Carbide round tools around 5/16" OD or larger.
  • Working parameters: 15 to 18 m/s = 2,953 to 3,543 ft/min
  • Package dimension (mm): 178x73x178
