Machining Troubleshooting

Chipping, poor finish, premature wear, oversized holes. Most tooling problems trace back to a handful of causes. Start with the quick fixes below, or open the full chart for the operation you are running.

The six problems we hear about most

What usually causes it, what to change first, and the tool on this site that helps you dial it in.

Chatter and vibration milling, turning, boring

Usual causes

  • Too much tool stickout or a weak holder
  • Workpiece not supported close to the cut
  • Spindle speed sitting on a resonant frequency
  • Too much radial engagement for the setup

Change first

  • Shorten the stickout and tighten the holding
  • Move the RPM up or down 10 to 15%
  • Reduce the stepover, keep the chip load
  • Try a variable-helix end mill
Poor surface finish all operations

Usual causes

  • Feed too high for the nose radius or corner
  • Built-up edge smearing the surface
  • Runout in the holder or a worn edge
  • Chips being recut

Change first

  • Lower the feed per rev or per tooth
  • Use a larger nose radius on finishing passes
  • Raise the cutting speed to clear built-up edge
  • Improve chip evacuation and coolant flow
Edge chipping inserts and end mills

Usual causes

  • Grade too hard for an interrupted cut
  • Feed too high on entry or exit
  • Unstable setup or chatter
  • Thermal shock from intermittent coolant

Change first

  • Move one step tougher in the same grade family
  • Ease the feed on entry, or roll into the cut
  • Use a stronger edge prep or larger corner
  • Run coolant fully on or fully off
Fast flank wear short tool life

Usual causes

  • Cutting speed too high for the material
  • Grade too soft or wrong coating
  • Feed too light, so the edge rubs instead of cutting
  • Abrasive material or poor coolant

Change first

  • Check SFM against the material and lower it
  • Move one step harder in the grade family
  • Raise the chip load to the recommended range
  • Choose a coating suited to the material
Oversized or rough holes drilling

Usual causes

  • Runout in the holder or a bent shank
  • Uneven point grind or worn margins
  • Feed too low, letting the drill wander
  • Chips packing in deep holes

Change first

  • Check runout at the drill point
  • Replace or regrind the drill
  • Bring the feed into the recommended range
  • Peck deep holes or use coolant-through
Broken taps tapping

Usual causes

  • Tap drill too small, too much thread engagement
  • Form tap run in a cut-tap hole
  • Chips packing in a blind hole
  • Not enough lubrication

Change first

  • Check the drill size for your tap type
  • Aim for 65 to 75% thread on cut taps, about 65% on form taps
  • Leave room at the bottom of blind holes
  • Use a tapping lubricant that stays on the tool

Full charts by operation

Every symptom we track, with the likely cause and the fix.

Still not cutting right?

Sometimes the chart is not enough. Our team has spent more than 30 years solving these problems on real shop floors. Tell us the material, the operation and what you are seeing.
